YW-150 Differential Pressure Transmitter With 316L All Stainless Steel Metal Isolation Diaphragm
| MOQ: | 1 |
| Standard Packaging: | carton |
| Delivery Period: | 5-8 work days |
| Payment Method: | L/C,D/A,D/P,T/T,Western Union |
| Supply Capacity: | 1000pcs/month |
Detail Information
Place of Origin
China
Brand Name
XINYI
Model Number
YW-150
Document
The Process Temperature:
-40-120℃
Shell Material:
316L
Overpressure Limit:
2 Times The Maximum Range
Electrical Connection:
M12x1
Ranges:
5~40 Bar
Work Temperature:
- 40-100 ℃
Sensor:
Capacitive Sensor
Measurement Range:
0-1000 KPa
Selling Units:
Single Item
Relative Humidity:
5~98%RH
Electric Interface:
1/2NPT, M20*1.5
Capability Change:
Less Than 0.16cm3
Operating Temperature:
-40 To 85°C
Protection:
Ip65
Highlight:
316L stainless steel pressure transmitter
,differential pressure transmitter with diaphragm
,intelligent pressure transmitter with warranty
Product Description
YW-150 Differential Pressure Transmitter With 316L All Stainless Steel Metal Isolation Diaphragm
The YW-150 differential pressure transmitter uses a silicon piezoresistive core as the signal measuring element. The measured differential pressure is applied to both ends of the transmitter, and the piezoresistive effect of semiconductor silicon material is utilized to achieve the conversion between differential pressure and electrical signals. The product has undergone strict testing and aging screening of components, semi-finished products, and finished products, and its performance is stable and reliable.
Working Principle
The differential pressure transmitter captures the differential pressure of the measured medium through double-sided pressure pipes. The differential pressure acts on the isolation diaphragms on both sides of the sensor and is transmitted to the measuring element through the sealing liquid. The measuring element converts the differential pressure signal into an electrical signal, which is amplified by a converter and outputs a standard 4-20mA DC signal to achieve accurate measurement of parameters such as pressure, liquid level, and flow rate.
Product Advantages
- Structure: Compact, lightweight, sturdy and vibration resistant, with a protection level of IP65, suitable for industrial environments
- Adjustable: Range and zero point can be continuously adjusted externally, and the intelligent model supports HART controller/software adjustment
- Migration ability: Positive migration can reach 500%, negative migration can reach 600%, intelligent range ratio of 100:1, flexible adaptation to different working conditions
- Damping: Adjustable damping to enhance measurement stability
| Product Name | Differential pressure transmitter |
|---|---|
| Pressure type | Differential pressure |
| Range | 0~20KPa-100KPa-2MPa |
| Output signal | 4-20mA,1-5,0-10V |
| Power supply | 9~24VDC |
| Precision | 0.5 |
| Compensation temperature | -20~80℃ |
| Operating Temperature | -20~80℃ |
| Protection level | IP65 |
| Insulation | 100MΩ/250VDC |
