YOKOGAWA EJX930A High-performance Multivariable Transmitter Pressure Transmitter
| MOQ: | 1 |
| Standard Packaging: | carton |
| Delivery Period: | 5-8 work days |
| Payment Method: | L/C,D/A,D/P,T/T,Western Union |
| Supply Capacity: | 100pcs/month |
Detail Information
Place of Origin
China
Brand Name
YOKOGAWA
Model Number
EJX930A
Document
Communication:
Hart
Output:
4-20mA
Media Temperature:
-40-120C
Accuracy:
+/- 0.5% Of Span
One Piece Packing:
Paper Box
Output Signal:
4-20 MA
Power:
24VDC（12-32VDC）5VDC（3-6.5Vdc）
Process Connection:
1/4" NPT
Sensor:
Capacitive Sensor
Housing Material:
Aluminum Alloy
Accuracy Grade:
0.075%
Calibration Certificate:
Included
Measurement Span:
0~62.2kPa
Highlight:
YOKOGAWA EJX930A pressure transmitter
,multivariable pressure transmitter with warranty
,intelligent high-performance pressure transmitter
Product Description
YOKOGAWA EJX930A High-performance Multivariable Transmitter Pressure Transmitter
Product Attributes
| Attribute | Value |
|---|---|
| Communication | HART |
| Output | 4-20mA |
| Media Temperature | -40-120°C |
| Accuracy | ±0.5% of span |
| One Piece Packing | Paper box |
| Output Signal | 4-20 mA |
| Power | 24VDC (12-32VDC) 5VDC (3-6.5Vdc) |
| Process Connection | 1/4" NPT |
| Sensor | Capacitive sensor |
| Housing Material | Aluminum alloy |
| Accuracy Grade | 0.075% |
| Calibration Certificate | Included |
| Measurement Span | 0~62.2kPa |
Product Description
The EJX930A high-performance multivariable transmitter features a single crystal silicon resonant sensor capable of measuring differential pressure, static pressure, process temperature, and calculating mass flow rate. Ideal for high static pressure applications with support for HART, FOUNDATION fieldbus, and RS485 Modbus protocols.
Core Features
- Multivariate measurement: Differential pressure accuracy ±0.04%, static pressure accuracy ±0.1%, external temperature measurement range -200~800°C (accuracy ±0.5°C)
- Mass flow calculation: Accuracy ±1.0%, suitable for flow measurement of gases, liquids, and vapors
- Communication protocol compatibility: Supports HART, Foundation fieldbus, and RS485 Modbus protocol
- Advanced functionality: HART7 protocol supports averaging tubes and conical flow meters. Foundation fieldbus models include standard functional blocks supporting PID control and advanced diagnostics
- Dynamic compensation technology: Real-time full density compensation through EJXMVTool™ software package with automatic flow coefficient optimization
Technical Specifications
| Range | 0~32MPa |
| Mass flow | ±1.0% |
| Differential pressure | ±0.04% |
| Static pressure (absolute) | ±0.1% |
| Process temperature | ±0.9°F |
| Differential pressure stability | ±0.1% URL/15year |
| Accuracy | ±0.04% |
| Output signal | 4-20mA |
